With the development of digital electronic technology, p2 LED display screen has become an important display equipment for modern information dissemination.
The p2 LED display has the characteristics of high definition, high brightness and high refresh rate, making it a leader in the LED display market.
This article P2 LED Display Quick Guide will quickly demonstrate all aspects of p2 LED displays, including p2 LED display specifications, advantages, maintenance, installation, etc.
Creative p2 LED display
1. What is p2LED display?
2. Specifications of P2 indoor LED display
3.p2 Specifications of indoor LED display
4.p2 What are the LED display products for LED display?
5.solution design of p2 LED display system
6.p2 Module type of LED display
7.p2 LED display cabinet
8. power supply of P2 LED screen
9.p2 LED display control system
10.p2 Installation method of LED display screen
11. Price factors affecting P2 LED display
12.p2 LED display VS LCD splicing screen
13.p2 LED display VS p3 LED display
14.Future development trends of p2 LED screens
15.Why choose LEGIDATECH’s p2 LED display
16.Conclusion
1. What is p2 LED display?
P2 LED display screen refers to an indoor or outdoor LED display screen with a pixel pitch of 2mm, which is a small-pitch LED display screen.
The p2 LED display has high contrast and high resolution, capable of displaying high-definition videos and pictures, and is suitable for various large-area high-definition display needs.
2. Specifications of P2 indoor LED display
P2 indoor LED display brightness: ≤600cd/㎡, color temperature 6500K
Indoor P2 LED display refresh rate: ≥3840hz. The high refresh rate can display the picture smoothly and protect your eyes to the greatest extent.
Indoor P2 LED display protection level: ip30, which can effectively prevent dust and moisture.
P2 indoor LED screen has the highest brightness contrast ratio: 4000:1, which can improve the color level and restore the most realistic colors.
Indoor P2 LED display flatness: ≥98%, when installing p2 LED display, truly seamless splicing can be achieved.
P2 indoor LED screen resolution: 25000/㎡, has a relatively high resolution and an optimal viewing distance of 2 meters, and is used in home theaters.
The indoor p2 LED display has low brightness and insufficient waterproof level, so it cannot be used in outdoor places. The advantage is that the price of indoor p2 LED display is much lower than that of outdoor p2 LED display.
3.p2 Specifications of outdoor LED screens
Outdoor p2 LED display brightness: ≤4500cd/㎡, color temperature 6500K, high brightness, clear and delicate display content can still be displayed under direct sunlight outdoors.
P2 outdoor LED display refresh rate: ≥3840hz. The high refresh rate makes the LED display more effective. It can be made into a 3D p2 LED display, which can effectively attract the audience’s attention and create more advertising value for customers.
Outdoor P2 LED display waterproof level: ip65, which can effectively prevent dust and moisture, and can also effectively prevent rain. Whether in frost, fog or rain, the outdoor p2 LED display can still work stably.
The highest contrast ratio of P2 outdoor LED screen brightness: 4000:1, which can improve the display effect of p2 LED display and display the most authentic product colors for outdoor advertising.
P2 outdoor LED display flatness: ≥98%, when installing the p2 LED display, truly seamless splicing can be achieved.
Outdoor P2 LED display resolution: 25000/㎡. Since outdoor p2 LED display has a relatively high resolution and an optimal viewing distance of 2 meters, it is used in squares, hotel and store entrances.
From this point of view, outdoor p2 LED displays have high waterproof levels and high brightness, and are widely installed in outdoor environments to display advertising content. The disadvantage is that the price of p2 outdoor LED display is higher than that of indoor p2 LED display.
4.p2 What LED display products are there for LED display?
p2.976 rental LED display and p2.604 rental LED display are habitually named p2 rental LED display by customers. It has the characteristics of high installation efficiency, good protective performance and convenient transportation.
P2 outdoor advertising LED display:
Due to the high resolution of the p2 outdoor LED display, the price of the p2 LED display is high.
Therefore, it is not suitable to be made into a large-area outdoor advertising LED display. Usually, outdoor p2 LED displays are made into small-area p2 poster screens and p2 light pole screens.
P2 outdoor light pole LED display
In order to enhance the attractiveness of advertising, we use indoor p2 soft modules and outdoor p2 soft modules to produce a variety of LED displays of different shapes according to specific scenes and advertising needs.
P2 creative LED display
With the continuous advancement of digital technology, p2 LED display is made into a naked-eye 3D LED display due to its high resolution.
5.p2 LED display system solution design
The P2 LED display is a complex digital system display device.
Contains various auxiliary equipment. Due to the extremely high resolution of p2, the usual auxiliary equipment includes computer servers, video processors, video splicers, audio matrix, sound systems, network systems and other comprehensive equipment. In such a complex signal system, how is each device connected?
We use an LED display topology diagram to show you how each device is connected. As shown below:
P2 LED display system topology diagram
6.p2 LED display module
p2 soft led module: p2 soft led module adopts a unified standardized size of 320mm×160mm. This type of module has undergone high and low temperature experiments and has stable performance.
Ultra-thin multi-layer PCB process design, front and rear bending can reach 145 degrees, and can produce outdoor cylindrical screens, internal and external arc curved screens, arc corner screens, and special-shaped screens.
LEGIDATECH’s team of engineers can design and customize creative LED displays for you.
SMD P2 indoor/outdoor LED module: The size of the SMD p2 indoor/outdoor LED module is 320mm×160mm, using Nationstar 2121 lamp beads and constant current driver IC. It has the characteristics of low temperature, energy saving and high refresh rate.
GOB p2 LED module: When installing the SMD p2 module, the LED lamp beads on the module are often damaged by external forces. Therefore, the GOB p2 LED module adds a layer of GOB glue on the surface of the SMD module to improve the protection capability of the p2 LED module.
COB P2 LED module: COB is a new LED display production process. The COB process is to directly weld the light-emitting chip to the PCB integrated circuit board, and cover the entire integrated circuit board with a layer of COB glue.
COB p2 LED modules have the characteristics of high protection, high stability and strong environmental adaptability. The price of such p2 LED modules is higher than SMD and GOB LED modules.
7.P2 LED Display Cabinet
Currently, LED display cabinet suppliers mainly provide three types of p2 LED display cabinets.
p2 rental LED display cabinet:
The size of the rental LED display cabinet is usually 500mm×1000mm and 500mm×500mm.
This kind of cabinet adopts the one-piece aluminum molding process, which has the characteristics of high precision, fast installation speed, and convenient transportation.
P2 front maintenance fixed LED display cabinet:
The box dimensions of the p2 front maintenance fixed LED display are generally 640mm×480mm and 640mm×640mm.
The p2 LED module is magnetically attracted to the LED box through the magnetic force of the magnet, so that the LED display can be maintained on the front of the screen.
The screen body is made of rolled aluminum, which can improve the flatness of the p2 LED display.
P2 special-shaped LED display cabinet:
The p2 special-shaped LED display cabinet is customized according to the drawings provided by the customer, and the raw material is usually made of iron.
The advantage of iron materials is that they are flexible and can be bent at will.
8.p2 LED display power supply
LEGIDATECH provides customers with p2 LED display power supplies of different brands. For example, there are Mengwell, G-energy , Rongdian Power, and Chuanglian Power.
Based on the different application scenarios of our customers’ p2 LED displays, we provide LED display power supplies that adapt to different application scenarios. The p2 LED display power supplies we provide have common features:
OVERVOLTAGE PROTECTION
When the output voltage exceeds 115-120%, the power supply will turn off the output and return to normal when restarting.
OVERLOAD PROTECTION
When the load current exceeds 115-120%, the power supply will activate the hiccup state, and the output will appear and disappear. It will automatically return to normal after the abnormality is resolved.
SHORT CIRCUIT PROTECTION
If the DC output interface of the power supply is connected reversely, the power supply will be automatically disconnected and will be automatically restored after the abnormality is resolved.
Chuanglian Power
9.p2 LED display control system
The P2 LED display control system has very good compatibility and can be compatible with many brands of LED display control systems.
For example, Nova system, LINSN control system, colorlight control system, HUIDU system, etc. At the same time, we can provide synchronous control systems and asynchronous control systems according to customer needs.
p2 LED display novastar receiving card
10.p2 Installation method of LED display screen
There are 6 control methods for P2 LED display screen, and different installation methods are developed according to different on-site installation environments.
Mosaic type:
The mosaic structure is to make a hole in the wall and embed the entire wall in the wall. It adopts front-end maintenance, and the display unit board is pasted on the frame structure using strong magnetic materials.
Suspended type:
suitable for screens with small area and light weight. The height of the screen is generally less than 6 meters and can be hung directly on the load-bearing wall. Standard hanging parts can be used for indoor load-bearing concrete roofs, and the length of hanging beams and booms depends on the site conditions.
Ordinary hanging installation:
It can be hung directly on the load-bearing wall. Large-area screens are generally maintained after use, and small screens are maintained before use without leaving space for maintenance.
Rotating bracket hanging installation:
It is suitable for displays with a weight greater than 100kg and a screen height and width greater than 1200mm. It must be installed on a load-bearing wall. Because it generally has a large area and is difficult to disassemble and assemble, the maintenance space is solved by rotating the screen.
Floor-standing installation:
Floor-standing installation is divided into two forms: fixed and movable. Movable installation with rollers is suitable for smaller and lighter displays.
Swing arm installation:
The swing arm installation is mainly to facilitate the maintenance of the back of the screen and the heat dissipation of the human screen. For swing-arm installation, the frame structure needs to be designed according to the area, weight and other parameters of the screen. The swing wall can be designed to be movable or fixed.
11. Price factors affecting P2 LED display
The main factors affecting the price of p2 LED display are raw materials and the brand of Led display supplier. The main raw materials of LED display are LED display lamp beads and constant current driver IC.
The quality of these two raw materials directly determines the display effect of the p2LED display, and accounts for 50% of the raw material cost.
Secondly, the better the brand of the LED display screen, the better the process of the LED display screen, the more complex the process, and the production cost will obviously increase.
12.p2 LED display VS LCD splicing screen
The brightness of the P2 LED screen is higher than that of the LCD splicing screen and can be installed in both outdoor and indoor environments. The brightness of the LCD splicing screen is relatively low and is only suitable for installation in indoor environments.
The P2 LED display is a small-pitch LED display, and its resolution is very close to the LCD splicing screen.
P2 LED display is more energy-saving and environmentally friendly than LCD splicing screen. The disadvantage is that the price of p2 LED display is higher than that of LCD splicing screen
The P2 LED display can achieve perfect seamless splicing when spliced. However, when LCD is spliced, there are obvious gaps between LCD display modules. The appearance of the LCD splicing screen is not as good-looking as the p2LED display.
13.p2 LED display VS p3 LED display
The difference between P2 LED screen and p3 LED display is mainly reflected in different resolutions, different display effects, and different prices.
The resolutions are different:
the pixel pitch of the p2 LED display is 2mm, while the pixel pitch of the p3 LED display is 3mm. In this way, under the same display area, the resolution of the p2 LED display is greater than the resolution of the p3 LED display.
Different display effects:
The p2 LED screen has a very small pixel pitch and can display more detailed videos and pictures. Compared with the p2 LED display, the display effect of p3 LED display is relatively not that good.
The price of P2 LED display is significantly higher than that of p3 LED display. Choose the appropriate p2 LED display or p3 LED display according to different application scenarios.
For example, if the viewing distance is greater than 3 meters, choose p3 LED display, if the viewing distance is less than 3 meters, choose p2 LED display.
14.p2 Future development trends of LED display screens
With the continuous development of small-pitch LED displays, the production process of p2 LED displays has become more and more mature.
LED displays with smaller spacing than p2 LED displays are constantly being invented. For example, p1.86 LED display screen, p1.5 LED display screen.
As the spacing of LED displays becomes smaller, the COB LED display production process is the most widely used production process for LED displays. SMD p2 LED screen are slowly being replaced by COB p2 LED displays.
15.Why choose LEGIDATECH’s p2 LED display
LEGIDATECH is a LED screen factory, and has p2 LED display product models for all corresponding scenarios of p2 LED screen. The LED display raw material suppliers we cooperate with are well-known brand suppliers.
So we design free p2 LED display technology solutions for you and provide the most suitable p2 LED display price. If you are looking for LED display supplier, please contact us immediately. Thanks
16.Conclusion
To sum up, there are more and more product models of p2 LED screen to meet the needs of full scene display. It has good stability and very bright display effect.
Moreover, the customized production of p2 LED display screen provides you with a better p2 LED display screen.
